Astm B151 UNS C71500, CuNi 70/30, CuNiFer, CuNi30fe1.6mn

Standard

:

EEMUA 144

Size:

:

DN15-DN500

16 bar

20 bar

ØD

Wall

Theoretical

Wall

Theoretical

thickness

weight

thickness

weight

nominal

actual

actual

actual

inch

ND

mm

mm

Kg/m

mm

Kg/m

0.125

10

1

0.26

1

0.26

0.25

12

1

0.31

1

0.31

0.38

10

16

2

0.79

2

0.79

0.5

15

20

2

1.01

2

1.01

0.75

20

25

2

1.3

2

1.3

1

25

30

2.5

1.93

2.5

1.93

1.25

32

38

2.5

2.5

2.5

2.5

1.5

40

44.5

2.5

2.95

2.5

2.95

2

50

57

2.5

3.83

2.5

3.83

2.5

65

76.1

2.5

5.17

2.5

5.17

3

80

88.9

2.5

6.07

2.5

6.07

4

100

108

3

8.85

3

8.85

5

125

133

3

10.95

3

10.95

6

150

159

3

13.14

3.5

15.29

7

175

193.7

3

16.07

3.5

18.7

8

200

219.1

4

24.17

4.5

27.12

10

250

267

4.5

33.18

5.5

40.39

12

300

323.9

5.5

49.18

7

62.3

14

350

368

6.5

65.99

8

80.89

16

400

419.1

7

81

9

103.64

18

450

457.2

8

100.93

9.5

119.45

20

500

508

8.5

119.24

11

153.54

24

600

610

10.5

176.79

13

217.97

28

700

711

12

235.58

15

293.22

32

800

813

13.5

303.14

17

380.06

36

900

914

15.5

391.14

19

477.6
