ASTM A928: American Society for Testing and Materials
Ferritic/Austenitic (Duplex) Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Metal.
Application: Refineries; Nuclear Plant; Aerospace Industry; Chemical Fertilizer; Petrochemicals' Oli & Gas and etc.
Chemical Composition | ||||||||||
UNS Designation | C max | Mn max | P max | S max | Si max | Cr | Ni | Mo | N | Cu |
S31803 | 0.03 | 2 | 0.03 | 0.02 | 1 | 21.0-23.0 | 4.5-6.5 | 2.5-3.5 | 0.08-0.20 | - |
S32205 | 0.03 | 2 | 0.03 | 0.02 | 1 | 22.0-23.0 | 4.5-6.5 | 3.0-3.5 | 0.14-0.20 | - |
S32750 | 0.03 | 1 | 0.03 | 0.01 | 1 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.20-0.30 | 0.50-1.00 |
Mechanical Properties | |||||
UNS Designation | Tensile Strength, min | Yield Strength, min | Elongation (mm) | ||
ksi | Mpa | ksi | Mpa | ||
S31803 | 90 | 620 | 65 | 450 | 25 |
S32205 | 90 | 620 | 65 | 450 | 25 |
S32750 | 116 | 795 | 80 | 550 | 15 |
Available Dimension Range | ||||||||||||||
OD(mm/inch) | Wall thickness (SCH) | |||||||||||||
10 | 20 | 30 | STD | 40 | 60 | XS | 80 | 100 | 120 | 140 | 160 | XXS | …100mm | |
21.3 (1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
26.7 (3/4'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
33.4 (1'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
42.2 (1 1/4'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
48.3 (1 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
60.3 (2'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
73 (2 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
88.9 (3'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
101.6 (3 1/2'') | √ | √ | √ | √ | √ | √ | ||||||||
114.3 (4'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | |||||
141.3 (5'') | √ | √ | √ | √ | √ | √ | √ | |||||||
168.3 (6'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
219.1 (8'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
273 (10'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
323.8 (12'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
355.6 (14'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
406.4 (16'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
457 (18'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
508 (20'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
559 (22'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |||
610 (24'') | √ | √ | √ | √ | √ | √ | √ | √ | ||||||
660 (26'') | √ | √ | √ | √ | ||||||||||
711 (28'') | √ | √ | √ | √ | √ | √ | ||||||||
762 (30'') | √ | √ | √ | √ | √ | √ | ||||||||
813 (32'') | √ | √ | √ | √ | √ | √ | √ | |||||||
864 (34'') | √ | √ | √ | √ | √ | √ | √ | |||||||
914 (36'') | √ | √ | √ | √ | √ | √ | √ | |||||||
965.2 (38'') | √ | √ | √ | √ | √ | √ | ||||||||
1016 (40'') | √ | √ | √ | √ | √ | √ | ||||||||
