ASTM A106 & A53

3.2 ASTM A106 & A53.jpg

ASTM A106& A53: American society for Testing and Materials Seamless Carbon Steel Pipe for High-Temperature Service Application: Oil, Gas and water delivery; Refinery, Boiler and Mechanical equipment manufacturer; structure construction; drilling, ship building and etc. ASTM A53: American society for Testing and Materials

ASTM A106 Chemical Requirements
Grade	Composition, %
Grade	C max	Mn	P max	S max	Si min	Cr max	Mo max	Others
A	0.25	0.27–0.93	0.035	0.035	0.1	0.4	0.15	...
B	0.3	0.29–1.06	0.035	0.035	0.1	0.4	0.15	...
C	0.35	0.29–1.06	0.035	0.035	0.1	0.4	0.15	...

Mechanical Properties
Grade
	A	B	C
Tensile strength, min:
ksi	48	60	70
Mpa	330	415	485
Yield strength, min:
ksi	30	35	40
MPa	205	240	275

Elongation Requirements: As per standard

Available Dimension Range

OD(mm/inch)

Wall thickness(SCH)

10

20

30

STD

40

60

XS

80

100

120

140

160

XXS

21.3 (1/2'')

√

√

√

√

√

√

√

√

26.7 (3/4'')

√

√

√

√

√

√

√

√

33.4 (1'')

√

√

√

√

√

√

√

√

42.2 (1 1/4'')

√

√

√

√

√

√

√

√

48.3 (1 1/2'')

√

√

√

√

√

√

√

√

60.3 (2'')

√

√

√

√

√

√

√

√

73 (2 1/2'')

√

√

√

√

√

√

√

√

88.9 (3'')

√

√

√

√

√

√

√

√

101.6 (3 1/2'')

√

√

√

√

√

√

114.3 (4'')

√

√

√

√

√

√

√

√

√

141.3 (5'')

√

√

√

√

√

√

√

168.3 (6'')

√

√

√

√

√

√

√

√

219.1 (8'')

√

√

√

√

√

√

√

√

√

√

√

√

√

273 (10'')

√

√

√

√

√

√

√

√

√

√

√

√

√

323.8 (12'')

√

√

√

√

√

√

√

√

√

√

√

√

√

355.6 (14'')

√

√

√

√

√

√

√

√

√

√

√

√

406.4 (16'')

√

√

√

√

√

√

√

√

√

√

√

√

457 (18'')

√

√

√

√

√

√

√

√

√

√

√

√

508 (20'')

√

√

√

√

√

√

√

√

√

√

√

√

559 (22'')

√

√

√

√

√

√

√

√

√

√

√

610 (24'')

√

√

√

√

√

√

√

√

660 (26'')

√

√

√

711 (28'')

√

√

√

√

√

762 (30'')

√

√

√

√

√

813 (32'')

√

√

√

√

√

√

864 (34'')

√

√

√

√

√

√

914 (36'')

√

√

√

√

√

√

ASTM A53 Chemical Requirements
Type	Grade	Composition %
Type	Grade	C	Mn	P	S	Cr	Mo	Others
S	A	0.25	0.95	0.05	0.045	0.4	0.15	...
S	B	0.30	1.20	0.05	0.045	0.4	0.15	...
E	A	0.25	0.95	0.05	0.045	0.4	0.15	...
E	B	0.30	1.20	0.05	0.045	0.4	0.15	...
F	A	0.30	1.20	0.05	0.045	0.4	0.15	...

Mechanical Properties
Grade
	A	B
Tensile strength, min:
ksi	48	60
Mpa	330	415
Yield strength, min:
ksi	30	35
MPa	205	240

Elongation Requirements:As per standard

Available Dimension Range

OD(mm/inch)

Wall thickness(SCH)

10

20

30

STD

40

60

XS

80

100

120

140

160

XXS

21.3 (1/2'')

√

√

√

√

√

√

√

√

26.7 (3/4'')

√

√

√

√

√

√

√

√

33.4 (1'')

√

√

√

√

√

√

√

√

42.2 (1 1/4'')

√

√

√

√

√

√

√

√

48.3 (1 1/2'')

√

√

√

√

√

√

√

√

60.3 (2'')

√

√

√

√

√

√

√

√

73 (2 1/2'')

√

√

√

√

√

√

√

√

88.9 (3'')

√

√

√

√

√

√

√

√

101.6 (3 1/2'')

√

√

√

√

√

√

114.3 (4'')

√

√

√

√

√

√

√

√

√

141.3 (5'')

√

√

√

√

√

√

√

168.3 (6'')

√

√

√

√

√

√

√

√

219.1 (8'')

√

√

√

√

√

√

√

√

√

√

√

√

√

273 (10'')

√

√

√

√

√

√

√

√

√

√

√

√

√

323.8 (12'')

√

√

√

√

√

√

√

√

√

√

√

√

√

355.6 (14'')

√

√

√

√

√

√

√

√

√

√

√

√

406.4 (16'')

√

√

√

√

√

√

√

√

√

√

√

√

457 (18'')

√

√

√

√

√

√

√

√

√

√

√

√

508 (20'')

√

√

√

√

√

√

√

√

√

√

√

√

559 (22'')

√

√

√

√

√

√

√

√

√

√

√

610 (24'')

√

√

√

√

√

√

√

√

660 (26'')

√

√

√

711 (28'')

√

√

√

√

√

762 (30'')

√

√

√

√

√

813 (32'')

√

√

√

√

√

√

864 (34'')

√

√

√

√

√

√

914 (36'')

√

√

√

√

√

√
